• Model NO.：DL-ISSL2-80W
• Illumination Time：12h
• Cell Type：LiFePO4 or Ternary Lithium
• Charging Time (H)：6
• Usage：Garden, Street, Highway
• IP Rating：IP65
• Certification：CE, RoHS, ISO
• Voltage：12,24V
• With Light Source：With Light Source
• Solar Panel：18V 100W Monocrystalline Silicon
• Battery：12.8V 50ah LiFePO4,12V 42ah Ternary Lithium Batter
• Lumen：11200-12800lm
• Viewing Angle：90*160
• Charge Time：6 Hours in Strong Sunshine
• Working Time：3-5 Continuous Rainy and Cloudy Days
• Working Temperature：-30-60 Celsius
• Colour Temperature：6000-6500K(Standard), 2800-3300K, 4000-4500K
• Height of Pole：8-10m
• Distance of Lights：25-30m
• Lamp Size：169*31*7(Cm)
• Net Weight：18.5kg
• Carton Size：179*41*17(Cm)
• Gross Weight：19.7kg
• Certificate：CE(EMC&LVD) & RoHS & IP65,Other Certificates Are a
• Transport Package：Carton,Wooden Frame
• Specification：169*31*7cm
• Trademark：DAWN
• Origin：China
• HS Code：9405409000
• Production Capacity：60000units,Year

Model NO.DL-ISSL2-20WDL-ISSL2-30WDL-ISSL2-40WDL-ISSL2-50WDL-ISSL2-60WDL-ISSL2-80WDL-ISSL2-100WLamp Power20W30W40W50W60W80W100WLed ChipsBridgelux/Nichia/or other brandsLumen2800
- 3200lm4200
- 4800lm

5600
-6400lm

7000
- 8000lm

8400
-9600lm

11200-12800lm

14000
-16000lm

Solar Panel Power18V 40W18V 60W18V 70W18V 80W18V 90W18V 100W18V 120WSolar Panel Type High Efficiency Monocrystalline SiliconSolar Panel Lifetime25 YearsBattery TypePowerful LiFePO4 Battery with 5 Years LifetimeInstalling Height5-6m6-7m6-7m7-8m7-8m8-10m8-10mInstalling Distance 15-18m18-20m18-20m20-25m20-25m25-30m25-30mWarranty Years3-5 YearsProduct Features?

1.Integrated design,all in?one solar LED street light,?solar panel,Led chips, battery,cotroller,motion sensor,etc,?all in(on) a light,without extra cable,?save shipping cost and labour cost.

2.Easy to?ship,carry and install.

3.Energy saving and environment friendly by perfect combination of solar power and LED lighting.

4.High capacity and long life Lithium battery,5-year theoretical working life and high-temperature resistance, make the whole light a longer life.

5.Safe and reliable rain-proof & water-proof design.

6.Alumina Alloy is used for main structure in order to preventing dusty and corrosion,is also good for heat dissipation.

7.Different power control according to time period, lower brightness when less people after midnight, in order to saving energy and improve practicability.
