• Model NO.：RPLT-6000
• Lumen Output：4*110000
• Total Height Top：9m
• Duty Stabiliser Legs：4*Manual
• Tyre Size：13 Inch
• Transport Package：Plywood Pallet , Plywood Case , Cartons
• Specification：ISO9001: 2000. CE
• Trademark：Robust Power
• Origin：China
• HS Code：9405409000
• Production Capacity：200sets,Month

Technical specificationsGENERATOR EngineKubota D1105-BG DieselEngine Type 3 cylinders,in line,water cooledPrime Power6.7kW / 50Hz     8.4kW/60HzEngine Aspiration1500rpm     1800rpmAlternatorStamford PI044F/4-pole,Brushless,excitationVoltage120,220,230,240VInsulationHFuel Tank Capicity(L)100 LFuel Consumption2.0 L/hMaximum Working Hours50Control systemGU3303 Digital controllerEngine Shutdown ProtectionLow oil press,over speed,over current,high temperature  detection,low fuel levelAyxiliary Sockets2Lighting Total Power Of Lamps4x1000WType Of LampMetal halide lampHousing MaterialsGalvanization Reflector HousingLumen4*110,000Lifetime Of Lamp5000 hoursWorking Temperature≤85°CConnection Protection IndexIP54Mast Type3-Sections Telescoping mast 9MTotal HeightTop 9MRotation358 degrees non-continuousOperate For ElevationWinch(Menchanical)Trailer  Tow HitchRing/ball hitchStabilier Supports4*ManualTire Size13 inchBrakesManualDIMENSION & WEIGHTDry/Net Weight830/780 kgExtend Dimension(LxWxH)4500*1350*1700mmShipping PackageIron Pallet 1800*1250*1450mm Plywood case 3500*300*260mm Carton 510*510*430mmContainer Load(20GP/40HQ)6/12 setsColorWhite/Yellow/Optional
