• Model NO.：type 01
• Power：15W-90W
• Technics：Drawbench
• Illumination Time：6h
• Cell Type：Lithium Battery
• Charging Time (H)：6
• Usage：Garden, Street
• IP Rating：IP65
• Certification：CE, RoHS
• Voltage：12,24V
• With Light Source：With Light Source
• LED Street Light：for Outdoorl Lighting
• Transport Package：Plastic Foam Paper,Carton
• Specification：CE
• Trademark：tienchan
• Origin：China
• HS Code：9405409000
• Production Capacity：3, 000 Sets Per Month

Basic Info.

Model NO. type 01 Power 15W-90W Technics Drawbench Illumination Time 6h Cell Type Lithium Battery Charging Time (H) 6 Usage Garden, Street IP Rating IP65 Certification CE, RoHS Voltage 12/24V With Light Source With Light Source LED Street Light for Outdoorl Lighting Transport Package Plastic Foam Paper/Carton Specification CE Trademark tienchan Origin China HS Code 9405409000 Production Capacity 3, 000 Sets Per Month

Product Description

We started to design and supply solar street light from 2009, and exported our products to Russia, America, Dubai, Poland, Finland, Czekh, Rwanda, Nigeria, etc.
All our solar panel, LED fitting, controller, battery, cable are CE or UL certified products, together with our 3 years' warranty, you never need to worry about quality or after sale service.

Solar panel:
1.  Mono-crystaline or poly-crystalline solar cell,high efficiency & conversion. Conversion efficiency:   11~17%
2. 10 years at 90% of the minimal rated power output
3. 25 years at 80% of the minimal rated power output
4.  Warranty :5 years,life time: more than 25 years

LED fitting:
1. Bridgelux LED chip from USA, lifespan is above 50000 hours.
2. IP grade:65, CRI> 75
3. Illumination efficiency:120-130 lm/w
4. Color temperature:4000k-5500k

Battery:
1. Valve controlled free maintenance deep cycle gel battery
2. Life span:5-7years
3. Warranty:2 years

Battery box:
1. ABS battery box, buried underground,  waterproof, IP67
2 .Excellent heat preserving performance.with air vent
3. Life span: 25 years.

Controller:

1. intelligent controller with the function of over charge and discharge protection, reverse connection protection.
2. It can switch on automatically according the level of darkness.  Energy saving mode is available. 3 sections  working power can be succeeded
3. Waterproof, IP: 67
4. Service life ≥5 years,Warranty:2 years

Light pole and panel support:
1. Hot-dip Galvanized with powder coat
2 .Material :Q235 steel, wall thickness: 4mm
3. Fitting arm dia.:60mm,
4. Anti-rust ,anti-corrosion,,lifespan for 30 years

Cable:
RVV type, copper core, for solar panel, fitting and battery connection
