• Model NO.：SMLN-200W
• Application：Highway, Square, Garden
• IP Rating：IP66
• Certification：CE, RoHS, CCC, UL, ISO, FCC, EMC, GS
• Voltage：DC12V
• Lighting Area：100m2
• Lighting Time：12 Hours
• LED Chip Brand：USA Bridgelux 210lm,W
• Controller：Automatic
• Back up Days：5 Days
• Maintenance：10 Years Free Maintenance
• Mounting Height：12-13m
• Distance Between Poles：30-35m
• Solar Panel：280W*2PCS
• Battery：Lead Battery
• Transport Package：Carton,Plywood Box,Pallet,Bubble Film,Woven Fabric
• Specification：A Grade
• Trademark：SunMaster
• Origin：Zhejiang, China.
• HS Code：9405409000
• Production Capacity：3, 000PCS ,Month

Basic Info.

Model NO. SMLN-200W Application Highway, Square, Garden IP Rating IP66 Certification CE, RoHS, CCC, UL, ISO, FCC, EMC, GS Voltage DC12V Lighting Area 100m2 Lighting Time 12 Hours LED Chip Brand USA Bridgelux 210lm/W Controller Automatic Back up Days 5 Days Maintenance 10 Years Free Maintenance Mounting Height 12-13m Distance Between Poles 30-35m Solar Panel 280W*2PCS Battery Lead Battery Transport Package Carton,Plywood Box,Pallet,Bubble Film,Woven Fabric Specification A Grade Trademark SunMaster Origin Zhejiang, China. HS Code 9405409000 Production Capacity 3, 000PCS /Month

Product Description

1.Remote control-Simple operation, change to different modes easily.
2.Wireless application-Integrated solar panel, LED, lithium battery, micro-controller and other accessories into one system, simple and stylish.
3.Micro-computer controlled-Combine motion sensor system, light control system and time control system.
4.Easy installation-No trench  required, no cables connection required, easy installation in 2 minutes.
5.Lithium battery-Adopt LiFe Po4 lithium battery to replace  gel battery, longer lifetime.
6.Modular design-All components are modular design and easy for expand.
7.Long time working- 12-14 hours each night,3-5 rainy days.



Specification



Lighting Time	10-14hrs/day(adjustable),3-7 rainy days back-up
Solar Panel	Poly solar panel 280W(optional)*2pcs,high efficiency,life span >25years 80% rated output power
Gel Battery	Capacity 200Ah/12v(optional)*2pcs,free maintenance,better weather-ability(-20ºC to +55ºC) Deep cycle 3500 times @ 30% DOD,low self discharge rate,life span>8 years
Solar Controller	MPPT/PWM,intelligent output power control,light on/off+time off,remote control,waterproof IP68 over-charge/discharge/over heat/over load/short circuit/anti-reverse protections,life span:>10 years
LED Lamp	LED power 200w,USA Bridgelux LED chip efficiency 200lm/w,Whole LED lamp efficiency 180lm/w, IP65 or higher,CRI>70Ra,C.T. 3000-6500k(optional),life span>100,000hrs
Light Pole	Q235 steel material,hot-dip galvanized and powder coating,equipped with lamp arm/solar panel mounting bracket/flange/fittings/foundation kit,wind resistance>150km/h,life span>20 years



Solar Battery Installtion Position



Working Mode



Product Benefits

Recommended configurations



Lamp	Pole	Solar Panel	GEL Battery	Lighting Space	Controller	Working Hours	Backup
20w	3-4m	50w*1pcs	40Ah*1pcs	>12m	MPPT	10-14 hours	3-5days
30w	4-5m	80w*1pcs	60Ah*1pcs	>14m	MPPT	10-14 hours	3-5days
40w	5-6m	100w*1pcs	80Ah*1pcs	>15m	MPPT	10-14hours	3-5 days
50w	6-7m	120w*1pcs	50Ah*2pcs	>17m	MPPT	10-14 hours	3-5days
60w	7-8m	150w*1pcs	60Ah*2pcs	>20m	MPPT	10-14 hours	3-5 days
70w	7-8m	180w*1pcs	70Ah*2pcs	>22m	MPPT	10-14 hours	3-5 days
80w	8-9m	200w*1pcs	80Ah*2pcs	>24m	MPPT	10-14 hours	3-5 days
90w	8-9m	120w*2pcs	90Ah*2pcs	>24m	MPPT	10-14 hours	3-5 days
100w	9-10m	130w*2pcs	100Ah*2pcs	>27m	MPPT	10-14 hours	3-5 days
120w	10-11m	150w*2pcs	120Ah*2pcs	>30m	MPPT	10-14 hours	3-5 days
140w	11-12m	180w*2pcs	140Ah*2pcs	>33m	MPPT	10-14 hours	3-5 days
150w	11-12m	200w*2pcs	150Ah*2pcs	>33m	MPPT	10-14 hours	3-5 days
180w	12-13m	250w*2pcs	180Ah*2pcs	>35m	MPPT	10-14 hours	3-5 days
200w	12-13m	280w*2pcs	200Ah*2pcs	>35m	MPPT	10-14 hours	3-5 days
