Shoebox LED Lighting Solar LED Street Light
Jinhua SunMaster Solar Co., Ltd.- Light Source：LED Light
- Color Temperature(CCT)：Cool White
- Lamp Body Material：Aluminum Alloy
- Lamp Power：30W
- Power Supply：Solar
- Average Life：>8000h
Base Info
- Model NO.：SMLN-30W
- Application：Highway, Square, Garden
- IP Rating：IP66
- Certification：CE, RoHS, ISO, FCC, EMC, GS, TUV
- Voltage：12V
- Maintenance：8 Years Free Maintenance
- Mounting Height：9m
- Battery：12ah
- LED Chip Brand：USA Bridgelux 210lm,W
- Solar Panel：20W
- Lamp Luminous Flux(Lm)：2700
- Distance Between Poles：10-15m
- Pole Height：5m
- Solar Cells：Mono or Poly High Efficiency A Grade
- Dim/Non-Dim：Both Can Do
- Approval：Ce,RoHS,Coc,IEC Soncap
- OEM/ODM/Customized：Available
- Warranty(Year)：5 Years
- Controller：Available
- Back up Days：3-5days and 7days and 365 Days
- Transport Package：Carton
- Specification：886x450x140mm
- Trademark：sunmaster
- Origin：Zhejiang, China
- HS Code：9405409000
- Production Capacity：1000PCS,Week
Description
Basic Info.
Model NO. SMLN-30W Application Highway, Square, Garden IP Rating IP66 Certification CE, RoHS, ISO, FCC, EMC, GS, TUV Voltage 12V Maintenance 8 Years Free Maintenance Mounting Height 9m Battery 12ah LED Chip Brand USA Bridgelux 210lm/W Solar Panel 20W Lamp Luminous Flux(Lm) 2700 Distance Between Poles 10-15m Pole Height 5m Solar Cells Mono or Poly High Efficiency A Grade Dim/Non-Dim Both Can Do Approval Ce/RoHS/Coc/IEC Soncap OEM/ODM/Customized Available Warranty(Year) 5 Years Controller Available Back up Days 3-5days and 7days and 365 Days Transport Package Carton Specification 886x450x140mm Trademark sunmaster Origin Zhejiang, China HS Code 9405409000 Production Capacity 1000PCS/WeekProduct Description
1.3-5 rainy /cloudy days backup 2.Dusk-to-Dawn 12 hours with dim energy saving mode 3.Lighting times can be individually adjusted with program switch. 4.Illuminance in operation depending on local site conditions (average daylight available) and customer-specific lighting times.
| Model NO. | SMLN-30W | Battery Type: | LiFePO4 24Ah/12.8V |
| Power: | 30W | Charging Time: | 6-10 hours |
| Color Temperature: | 6000-6500K | Discharging Time: | 10-12 hours |
| Certificate: | CE/ROHS/IP65 | Product Dimension: | 886*450*140mm |
| Viewing Angle: | 120 | Packing Dimension: | 940*510*200mm |
| Working temperature : | ,-20 ~ +70 | Product Weight | 17KG |
| Lamp Efficiency: | 170 lm/w | Material: | Aluminum Alloy |
| Led chip brand: | USA Bridgelux LED chip | Install Height: | 6-7 m |
| Solar Panel: | 18V 60W Mono-crystalalline | Warranty: | 3 years |
