Integration SLS20W LED for Home Power 12V Street Lights

Foshan Tanfon Energy Technology Co., Ltd.
  • Light Source：LED Lamp
  • Lamp Body Material：Aluminum
  • Light Type：Solar
  • Color Temperature：Pure White
  • Power：≥30W
  • Technics：Electroplating

Base Info

  • Illumination Time：8-12h Photoinduction
  • Cell Type： Lithium Battery
  • Charging Time (H)：8
  • Usage：Street
  • IP Rating：IP65
  • Certification：CE, RoHS
  • Voltage：18V
  • With Light Source：With Light Source
  • Produce Name：Solar Street Light
  • Place of Origin：Foshan
  • Model Number：8W-120W
  • System Parts：Solar Panel+LED Lights+Battery+Pole
  • Solar Panel：Mono or Poly(Optional)
  • LED Lampshade Materias：Toughened Glass
  • Battery：Gel Battery or Lead Acid Battery(Optional)
  • Warranty：3 Years
  • Service：Ship The F Materilas During The Warranty
  • Transport Package：1set Carton Box
  • Specification：CE
  • Trademark：TANFON or OEM or Neutral
  • Origin：Foshan
  • HS Code：9405500000
  • Production Capacity：100000 Set ,Yes

Description

TANFON A-SLS60W solar street/Garden Light system with mobile APPSolar panel:

85W/18V Monocrystalline sillicon solar panel, waterproof resign package. Sillicon chip import from Germany. PV efficiency>19%

Solderability and tension ensured by quality printing paste

LED Lamp:

60W High Lumens

Lumen(LM): 6500-7000

Chip import from USA

LED Chip: High Brightness Bridgelux, high efficiency, low loss, luminous flux 110lm/w


Battery:44AH High efficiency Lithium Battery
Long life cycle, >2000 times deep cycle, 8 times of lead acid battery
No memory effect, highly efficient charge anytime. no reduction of capacity
low self-discharge rate <3% monthlyMPPT Controller:Multicrest MPPT tech, adapts to the solar panel which is under shadow or partly damaged
Auto identify day/night
Very low dormancy loss: 0.06WColour Temperature7200-8000KDischarge timeOver 36 hours, considering 3-5 rainy daysWorking temperature-30~+60 degreesWaterproof rateIP65Mounting heightSuggest 7M, install distance: 25m to 30 mWarranty3 years


Tanfon 8W-120W solar street light system/Garden light is Integration design (panel+battery+LED lamp all in one box)

need more details, please send inquiry to us, we will do our best service to show you suitable solar power light system.



Advantages of our solar street lights:
1.High Brightness Cree XB-D LED Chip, luminous efficiency of whole lamp reach 100lm/W
2.High luminance effect, realizing energy saving by 70% comparing with traditional light source.
3.Power factor over 95%, harmonic distortion rate less than 15%;
4.Amazingly long lifetime over 50, 000 hours, one-time investment, long-time benefit;
5.Adopt digital constant-power technology, realizing control of LED power;
6.Unique one-time die-casted aluminum shell structure, realizing excellent heat dissipation;
7.Stable LED working point, low temperature rise, low brightness decline.
Integration SLS20W LED for Home Power 12V Street Lights


FAQ

Q1. Can I have a sample order for led light?

A1: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2.How long does the solar power can be stored?

A2:Solar power of the integrated solar street light can be stored for 6 months after the batteries are full charged. Please examine, and charge periodically after long time transportation to prevent damage.

Q3: How many cycles full charge&discharge about your battery?

A3: In 50% discharging deepness, it can be cycled for 1,200 times; in floating charging and discharging status, it can be cycled for 5000~6000 times.

Q4. What is the advantage of the battery?

A4: Our integrated solar street light adopts long life lithium battery for storing energy, charging temperature at day time is between: 0ºC-60ºC,when temperature goes lower than 0ºC,the control system will stop automatically to protect the batteries, and it will revive to charge the batteries while temperature goes higher than 0ºC.Discharging temperature at night is between:-20ºC-60ºC, any ambient beyond it will bring damage to the batteries.

Q5. How to control the luminance of the solar street light?

A5:Our solar street light adopts Microwave sensor control & brightness sub-regulation. Here we especially introduce the brightness sub-regulation. Use a computer system to set the brightness according to the time change. For example, from 6:00p.m. to 12:00p.m., 100% brightness; from 0:00a.m. to 06:00a.m., 20% or 30% brightness. In that way, this new product can instead common LED street light.

Q6. What is the mounting height?

A6: We suggest the solar street light of 20W, 30W, 40W for 3-5m, the solar street light of 50W, 60W, 80W for 6-8m.

Q7. What is the distance?

A7: For the distance, we suggest the solar street light of 20W, 30W, 40W for 10-15m, the solar street light of 50W, 60W, 80W for 20-25m.

Q8. The controller of your solar street light has dual time control function?

A8: our solar charge controller is designed with dual time control function, you can set up the lighting time and divide it into two parts, like 12 hours (6 hours full power lighting + 6 hours half power lighting)

Q9. Is it OK to print my logo on led light product?

A9: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q10: Do you offer guarantee for the products?

A10: Yes, we offer 3 years warranty to our products.


Customer Visiting:
Integration SLS20W LED for Home Power 12V Street Lights
We offer best quality with best service:

Loading container
Integration SLS20W LED for Home Power 12V Street Lights

We accept OEM and small trial orders, contacting with us now for more information. All inquiries will be replied with in 24 hours.
