• Model NO.：STL12-140W
• Lamp Power：140W
• Power Supply：Solar
• Average Life：80000h
• Application：Highway, Square, Garden
• IP Rating：IP66
• Certification：CE, RoHS, CCC, UL, ISO, FCC, EMC, GS
• Voltage：DC12V
• Back up Days：4 Days
• Maintenance：9 Years Free Maintenance
• Mounting Height：11-13m
• Distance Between Poles：35-37
• Solar Panel：140W*2PCS
• Battery：Lead Battery
• Working Mode：Full Power and Energy Saving Mode
• Pole：Q235
• Lighting Area：100m2
• Lighting Time：Over 5 Nights
• Transport Package：Carton,Plywood Box,Pallet,Bubble Film,Woven Fabric
• Specification：A Grade
• Trademark：SunMaster
• Origin：Zhejiang, China.
• HS Code：9405409000
• Production Capacity：3, 000PCS ,Month

Basic Info.

Model NO. STL12-140W Lamp Power 140W Power Supply Solar Average Life 80000h Application Highway, Square, Garden IP Rating IP66 Certification CE, RoHS, CCC, UL, ISO, FCC, EMC, GS Voltage DC12V Back up Days 4 Days Maintenance 9 Years Free Maintenance Mounting Height 11-13m Distance Between Poles 35-37 Solar Panel 140W*2PCS Battery Lead Battery Working Mode Full Power and Energy Saving Mode Pole Q235 Lighting Area 100m2 Lighting Time Over 5 Nights Transport Package Carton,Plywood Box,Pallet,Bubble Film,Woven Fabric Specification A Grade Trademark SunMaster Origin Zhejiang, China. HS Code 9405409000 Production Capacity 3, 000PCS /Month

Product Description

1.Material:heat-emission aluminum lamp body makes the lamp more durable.
2. Solar Panels:High efficiency A grade moudule produce more energy for the lamp in limited space.
3.Battery: LiFePO4 environmentally friendly material for longer lifespan.
4.LED Light:BRIDGELUX 210lm/watt LED chip, give brighter illumination.
5. Controller:MPPT type 15%-20% higher than normal PWM controller.
6. Lighting time:6 to 14 hours per day and 3 to 5 days backup.
7. Infrared Motion Sensor for intelligent lighting and energy saving.
8.Easy installation only needs 60 seconds and totally free maintenance.



Specification



Lighting Time	10-14hrs/day(adjustable),3-7 rainy days back-up
Solar Panel	Poly solar panel 180W(optional)*2pcs,high efficiency,life span >25years 80% rated output power
Gel Battery	Capacity 140Ah/12v(optional)*2pcs,free maintenance,better weather-ability(-20ºC to +55ºC) Deep cycle 3500 times @ 30% DOD,low self discharge rate,life span>8 years
Solar Controller	MPPT/PWM,intelligent output power control,light on/off+time off,remote control,waterproof IP68 over-charge/discharge/over heat/over load/short circuit/anti-reverse protections,life span:>10 years
LED Lamp	LED power 140w,USA Bridgelux LED chip efficiency 200lm/w,Whole LED lamp efficiency 180lm/w, IP65 or higher,CRI>70Ra,C.T. 3000-6500k(optional),life span>100,000hrs
Light Pole	Q235 steel material,hot-dip galvanized and powder coating,equipped with lamp arm/solar panel mounting bracket/flange/fittings/foundation kit,wind resistance>150km/h,life span>20 years



Solar Battery Installtion Position



Working Mode



Product Benefits

Recommended configurations



Lamp	Pole	Solar Panel	GEL Battery	Lighting Space	Controller	Working Hours	Backup
20w	3-4m	50w*1pcs	40Ah*1pcs	>12m	MPPT	10-14 hours	3-5days
30w	4-5m	80w*1pcs	60Ah*1pcs	>14m	MPPT	10-14 hours	3-5days
40w	5-6m	100w*1pcs	80Ah*1pcs	>15m	MPPT	10-14hours	3-5 days
50w	6-7m	120w*1pcs	50Ah*2pcs	>17m	MPPT	10-14 hours	3-5days
60w	7-8m	150w*1pcs	60Ah*2pcs	>20m	MPPT	10-14 hours	3-5 days
70w	7-8m	180w*1pcs	70Ah*2pcs	>22m	MPPT	10-14 hours	3-5 days
80w	8-9m	200w*1pcs	80Ah*2pcs	>24m	MPPT	10-14 hours	3-5 days
90w	8-9m	120w*2pcs	90Ah*2pcs	>24m	MPPT	10-14 hours	3-5 days
100w	9-10m	130w*2pcs	100Ah*2pcs	>27m	MPPT	10-14 hours	3-5 days
120w	10-11m	150w*2pcs	120Ah*2pcs	>30m	MPPT	10-14 hours	3-5 days
140w	11-12m	180w*2pcs	140Ah*2pcs	>33m	MPPT	10-14 hours	3-5 days
150w	11-12m	200w*2pcs	150Ah*2pcs	>33m	MPPT	10-14 hours	3-5 days
180w	12-13m	250w*2pcs	180Ah*2pcs	>35m	MPPT	10-14 hours	3-5 days
200w	12-13m	280w*2pcs	200Ah*2pcs	>35m	MPPT	10-14 hours	3-5 days
