Solar Street Lighting Ce RoHS with 56W LED 6m Pole

Guangzhou Glory Advertising Signs Co., Ltd.
  • Light Source:LED, 56W DC24V
  • Lamp Body Material:Aluminum Alloy
  • Power:≥30W
  • Illumination Time:12h
  • Cell Type:Ni-MH Battery
  • Usage:Street

Base Info

  • Model NO.:GL-V46
  • IP Rating:IP65
  • Certification:Ce, RoHS
  • Input Voltage(V):24
  • Lamp Power(W):56
  • Lamp Luminous Flux(Lm):5600
  • Lamp Luminous Efficiency(Lm/W):100
  • Color Temperature(CCT):Cool White
  • Working Lifetime(Hour):50000
  • Application:Commercial
  • Transport Package:Wooden Case for Export
  • Specification:Certification: CE SGS ROHS
  • Trademark:Glory
  • Origin:Guangzhou, China
  • Production Capacity:1000 Piece,Pieces Per Week

Description

System No.: GL-SLX8-56WSolar Panel:2pcs*120Wp 18V, high-efficiency polycrystalline PV module     Light Source:56W DC24V; LED street lamp, Bridgelux 45MIL or 50MIL led chips, 110~120LM/WController:12V/24V 20A, light/time intelligent control, PWM mode; waterproof, IP67 guard level; various protections       Battery:2pcs*12V120AH, solar special lead-acid battery, fully sealed deep cycle free maintenance typeBattery Box:Hot dip galvanized battery boxPole Set:6-8m high, Q235 steel pipe; hot-dip galvanized and spray coated treatment, rustproof; including solar panel bracket and lamp arm, foundation not includedWorking time:10 -12 hours/day  (6hrs full power + 6hrs half power lighting mode) , battery capacity providing 2-3 continuous cloudy or rainy days backup
