• Model NO.：QC-floodlight-001-100
• Illumination Time：8h
• Cell Type：Lithium Battery
• Charging Time (H)：4
• Usage：Garden, Street
• IP Rating：IP65
• Certification：CE, RoHS
• Voltage：12,24V
• With Light Source：Without Light Source
• Item Type：Street Lights
• Product Name：Product Name
• LED Street Light：LED Street Light
• Integrated Solar Street Light：Integrated Solar Street Light
• Transport Package：LED Lamp: Carton Packaging; Solar Panel: Carton a
• Specification：height 15-45 meter
• Trademark：qichuang
• Origin：Jiangsu
• HS Code：9405409000
• Production Capacity：50000

Basic Info.

Model NO. QC-floodlight-001-100 Illumination Time 8h Cell Type Lithium Battery Charging Time (H) 4 Usage Garden, Street IP Rating IP65 Certification CE, RoHS Voltage 12/24V With Light Source Without Light Source Item Type Street Lights Product Name Product Name LED Street Light LED Street Light Integrated Solar Street Light Integrated Solar Street Light Transport Package LED Lamp: Carton Packaging; Solar Panel: Carton a Specification height 15-45 meter Trademark qichuang Origin Jiangsu HS Code 9405409000 Production Capacity 50000

Product Description

Airport Square Football Field Street Outdoor Galvanized Steel Round Conical PolygonalHigh Mast Light Pole Tower

Product Parameters
The pole is made of high quality material steel Q235 and the weld is smooth. Galvanization by inside and outside hot dip galvanizing. 15 years no rust.

height:4m wall thickness:2.5mm                   diameter:φ60/φ120 material:steel Q235 Hot-dip galvanizing:80μm plastic spraying layer:100μm flange plate:240mm*240mm*14mm lumbar type hole:24mm*50mm lamp arm:φ48mm*2.0mm*1m Solar panel support:20mm*30mm*1.5mm	height:5m Wall thickness:2.5mm                  diameter:φ60/φ140 material:steel Q235 Hot-dip galvanizing:80μm plastic spraying layer:100μm flange plate:260mm*260mm*14mm lumbar type hole:24mm*50mm lamp arm:φ48mm*2.0mm*1m Solar panel support:20mm*30mm*1.5mm
height:6m wall thickness:3mm                    diameter:φ60/φ180 material:steel Q235 Hot-dip galvanizing:80μm plastic spraying layer:100μm flange plate:260mm*260mm*16mm lumbar type hole:24mm*50mm lamp arm:φ60mm*2.0mm*1.2m Solar panel support:20mm*30mm*1.5mm	height:7m wall thickness:3mm                    diameter:φ60/φ180 material:steel Q235 Hot-dip galvanizing:80μm plastic spraying layer:100μm flange plate:280mm*280mm*16mm lumbar type hole:24mm*50mm lamp arm:φ60mm*2.0mm*1.2m Solar panel support:20mm*30mm*1.5mm
height:8m wall thickness:3.5mm                  diameter:φ80/φ180 material:steel Q235 Hot-dip galvanizing:80μm plastic spraying layer:100μm flange plate:280mm*280mm*16mm lumbar type hole:24mm*50mm lamp arm:φ60mm*3.0mm*1.5m Solar panel support:20mm*30mm*1.5mm	height:9m wall thickness:4mm                    diameter:φ80/φ180 material:steel Q235 Hot-dip galvanizing:80μm plastic spraying layer:100μm flange plate:300mm*300mm*16mm lumbar type hole:24mm*50mm lamp arm:φ60mm*3.0mm*1.5m Solar panel support:20mm*30mm*1.5mm
height:10m wall thickness:4mm                      diameter:φ80/φ200 material:steel Q235 Hot-dip galvanizing:80μm plastic spraying layer:100μm flange plate:300mm*300mm*18mm lumbar type hole:24mm*50mm lamp arm:φ60mm*3.0mm*1.5m Solar panel support:20mm*30mm*1.5mm	height:11m wall thickness:4.5mm                   diameter:φ80/φ210 material:steel Q235 Hot-dip galvanizing:80μm plastic spraying layer:100μm flange plate:350mm*350mm*18mm lumbar type hole:24mm*50mm lamp arm:φ60mm*3.0mm*1.8m Solar panel support:20mm*30mm*1.5mm
height:12m wall thickness:4.5mm                  diameter:φ80/φ220 material:steel Q235 Hot-dip galvanizing:80μm plastic spraying layer:100μm flange plate:350mm*350mm*20mm lumbar type hole:24mm*50mm lamp arm:φ60mm*3.0mm*1.8m Solar panel support:20mm*30mm*1.5mm	height:13m wall thickness:4.5mm                  diameter:φ90/φ240 material:steel Q235 Hot-dip galvanizing:80μm plastic spraying layer:100μm flange plate:400mm*400mm*20mm lumbar type hole:24mm*50mm lamp arm:φ60mm*3.0mm*1.8m Solar panel support:20mm*30mm*1.5mm
height:14m wall thickness:5.0mm                   diameter:φ90/φ240 material:steel Q235 Hot-dip galvanizing:80μm plastic spraying layer:100μm flange plate:450mm*450mm*22mm lumbar type hole:24mm*50mm lamp arm:φ60mm*3.0mm*1.8m Solar panel support:20mm*30mm*1.5mm

FAQ



Q1: Can I have a sample order for led light?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?
A: Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than

Q3. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q4: Do you offer guarantee for the products?

A: Yes, we offer 2-5 years warranty to our products.

Q5:How to Choose the System Voltage  12V or 24V or for normal street Light ?

A:We can design the system for 12v or 24v according to the LED light power.

Q6. How to proceed an order for led light?
A: Firstly,let us know your requirements or application.
    Secondly,We quote according to your requirements or our suggestions.
    Thirdly,customer confirms the samples and places deposit for formal order.
    Fourthly,We arrange the production.
